Introduction

Important parts

1 Optical sight

2 Telescope

3 Vertical drive

4 Battery GEB111 (optional)

5 Battery spacer for GEB111

6 Battery holder for GEB111/

GEB121/GAD39

7 Focussing graticule

8 Focussing telescope image

9 Detachable carrying handle with

mounting screws

10 Foot screw

11 Objective

12 Battery adapter GAD39 for 6

single cells (optional)

13 Battery GEB121 (optional)

14 Display

15 Keyboard

16 Circular level

17 Horizontal drive

1

3

8

9

10

16

15

14

2

4

T100Z02

7

11

5

6

17

13

12
