18

Simple measurements

T105/T110-1.3.0en

8

12

Changing the laser intensity.

Possible adjustments:
Intensity min.
Intensity 25%
Intensity 50%
Intensity 75%
Intensity max.

Switch off laser plummet with

.

Laser intensity

External influences may require the
adjustment of the intensity of the
laser plummet.

Adjusting the laser intensity.

If the instrument is equipped with a
shiftable tribrach it can be aligned to
the station point by slight shifting.

1. Loosen screw.
2. Shift instrument.
3. Fix instrument by turning screw.

Centring with shiftable tribrach

T100Z23
