6 Start-up Leica DISTO™ D3 760498a en
EN
F
E
P
A built-in sensor automatically detects the orienta-
tion of the positioning bracket and adjusts the zero
point of the instrument accordingly.
Keypad
See figure {E}:
1 ON / DIST (On/measuring) button
2 Plus (+) button
3 Minus (-) button
4 Area / volume button
5 Indirect measurement (Pythagoras) button
6 Reference button
7 Functions button
8 Timer button
9 Storage button
10 Menu/equal button
11 Clear/off button
Display
See figure {F}
1 Laser active
2 Reference (front)
3 Reference (rear)
4 Reference (corner stop)
5 Measuring with the tripod
6 Stake out function
7 Single Pythagorean measurement
8 Double Pythagorean measurement
9 Double (partial height) measurement
10 Illumination
11 Save constant value, call up constant value
12 Historical memory, call up values
13 Battery status
14 Timer
15 Area/volume
16 Tilt
17 Horizontal distance measurement using tilt
18 Room corner angle function
19 Menu
20 Continuous laser
21 Reset
22 Reference (tripod)
23 Beep
24 Circumference
25 Wall area
26 Ceiling area
27 Intermediate line 1
28 Intermediate line 2
29 Intermediate line 3
30 Summary line
