Page 8
FUSE
RED
PINK/WHITE
30A
FUSE
RED
30A
+
-
BROWN
PINK
FUEL
ENGINE
BATTERY
PUMP
ECU
GRAY
+
STARTER
-
COIL
IGN
OR
ACC
H/V/AC
Diagram not to scale,
for illustration purposes
only. Your vehicle may
differ.
IGN 2
ACC 2
TOP
WHITE
STRT 2
10A
FUSE
PARKING
LIGHTS
IF NECESSARY
7-PIN High Current
Connector
IGN. SWITCH
(+) or (-)
NOTE: Heavy duty/High Current Ignition circuits greater than 30 AMPS. Industrial vehicles, dual AC, etc. require high-
current relays. DO NOT use the outputs of the RS900 for High-Current systems or you will risk damaging the unit and
creating a hazardous condition! Use Part #CS-403 relays for circuits up to 70 amps.
WIIRNG: 3-PIN POWER DOOR LOCK CONNECTOR
