ClearSounds AMPLIFIED FREEDOM PHONE WITH FULL CLEARDIGITAL POWER CSC1000 - Manual (Page 13)

13 – ENGLISH
1.
Slide the handset hanger tab out and reverse its position
(rotate it 180 degrees). Slide it back into place so that
the hook points up (see Diagram 6). This will keep the
handset from falling out of the cradle when it is mounted
on the wall.
2.
Plug the AC power adapter into the jack on the back of
the telephone. Wait until the phone is completely setup
before plugging the AC adapter into the electrical outlet
or surge protector. NOTE: The adapter is required for
the telephone to work correctly.
3.
Plug the 8-inch short phone cord into the telephone
jack on the phone, run the phone cord underneath the
wall plate adapter and through the opening. The excess
telephone line can be positioned into the recessed area
on the bottom of the mounting plate.
4.
Insert the wall plate adapter by holding the wall plate
adapter so that the raised mounting pins line up with the
phone’s keyholes on the back. Once the holes are lined
up, push the wall plate adapter in towards the phone and
then slide the plate upwards until it is securely seated
on the phone (see Diagram 7).
5.
With the wall plate adapter installed, plug the 8-inch
short phone cord into the jack on the wall.
Screw head
Wall
Diagram 9 Diagram 10
