AFG Burner Manual
#
Part No.
Description
1
Burner Housing
Assembly
2
Specify*
Air Band - Specify # of slots
3
Specify*
Air Shutter - Specify # of slots
4
21807U
Valve Cordset
Not Shown
21887U
PD
Timer Delay Cordset
5
2184404U
CleanCut Pump
6
5394
Copper Oil Line - 8”
7
3666
Splined Nut
8
3493
Escutcheon (F & L1/L2 heads)
5941
Head
Adjusting Plate (V1 head)
9
2139
Hole Plug
10
2454
Coupling
11
31231U (AFG)
31841U (AF)
Air Guide (AFG)
Air Inlet Bell (AF)
12
2999U (AFG)
2459U (AF)
Blower Wheel (AFG)
Blower Wheel (AF)
13
21805U
4189
PSC Motor
Mounting Screws
14
5770
Electrical Box
15
7505A
Replaces R7184A
- Interrupted Ignition
7505B
Replaces R7184B - Pre-time
7505P
Replaces R7184P
- Pre and Post-
time**
16
51771U
Igniter & Base Plate
#
Part No.
Description
17 & 18
51304
Igniter Gasket Kit
19
5880
Low Firing Rate Baf
fl e
20
7006U
Cad Cell Detector
21
5780
Electrode Kit - F Head up to 9”
5782
Electrode Kit - F Head over 9”
5940
Electrode Kit - M Head up to 9”
22
5432
3616
Universal Flange w/ Gasket
Gasket Only
23
Specify *
Air
Tube Combination
24
Specify *
Heat Shield, Ceramic or Fiber
25
5685
Pedestal Kit
26
2182602U
Solenoid V
alve Kit (delay)
27
52064xxU*
Cover
* Contact your Beckett Representative for part number
and pricing.
** Contact your Beckett Representative for available pre
and post time settings.
