Obverse:
LED indicator show:
Electrify input: Status1and Status2 blinking 3times
Main mode undiscover target facility: Status2 blinking, 1 /sec
Data transmit: Status2 off
No data transmit: Status2 on
Setting error: Status1 blinking, 1/sec
data buffer full: Status1 on
【Simply use setting】
Introduction the equipment simple use as following(visit the facility by create a dummy serial
port ).
Running the serial connection wizard, interface display as below. Setting step by step.
Note: Create a Virtual serial port to visit the facility, need to close the firewall before install
link guide process. Especially the Windows XP system .
Suggestion: Hold the default parameter of system during the installation . The user may also
according to the environment need choice device appropriate working pattern and other options。
Step 1: Click on “Next”
Step 2: Select the first item (create a link between a virtual
serial port and a device server). And then click on “Next”
