HXJZ-873 Mini Power Wireless Module User’s Manual
Channel and frequency list
Channel Frequency Channel Frequency
1 430.2000MHZ 9 458.5250MHZ
2 431.4288MHZ 10 459.1250MHZ
3 431.7360MHZ 11 459.5250MHZ
4 430.5072MHZ 12 460.1250MHZ
5 434.6940MHZ 13 460.5250MHZ
6 434.2332MHZ 14 461.1250MHZ
7 433.1580MHZ 15 461.5250MHZ
8 433.9260MHZ 16 462.1250MHZ
Technical specification of HXJZ-873
Modulation mode: GFSK
Working frequency: 433MHZ
Transmission power: <500mW
Receiving sensitivity: -123dBm
Transmitting current:: <360mA
Receiving current: <45mA
Sleeping current: <1mA
Channel speed rate: 1200/2400/4800/9600/19200/38400Bit/s, User can Choose one
Interface speed rate: 1200/2400/4800/9600/19200/38400Bit/s, User can Choose one
Change time for receiving and sending: <10ms
Interface data format: 8E1/8N1/8O1
Power supply: 5± 0.5V DC
Working temperature: -20℃～85℃
Working humidity: 10%～90% relative humidity without condensation
Dimension: 58mm*38mm*10 mm
Attachable Communication with Model: JZ871/JZ872/HXJZ-873/JZ878
Model and name
JZ 873 -T
T: TTL interface
2: 232 interface
4: 485 interface
Naked board
Company logo
