HXJZ-871 Mini Power Wireless Module User’s Manual

HXJZ-871 Power supply and sleep mode

1. Power supply

HXJZ-871 uses DC power supply with voltage of +5V. It can also share power supply with other

equipment, however, the high quality power supply with desirable ripple factor should be selected. In addition,

the reliable grounding must be used if there is other device in the system equipment. In case of failure to

connect with the earth, it can form its own grounding but it must be absolutely separated from the municipal

electric supply.

2. Sleeping function

HXJZ-871 had sleeping and no-sleeping version.

The current ofHXJZ-871 in the sleeping state is 1Ua. Users must tell which version will be chosen

before place the order in advance (No sleeping is default).

For

sleeping

version,

users

can

open

and

close

the

sleeping

function

by

themselves.

HXJZ-871 with the sleeping function has two awakening way, one is hardware awakening way, another

is interface awakening way (air awakening will be reserved) Hardware awakening is achieved by the Pin 5

input to the high level and input low level to awake.

Awaken from Interface is achieved by users send designate protocol data by HXJZ-871 interface to open

or awake. HXJZ-871 with the function of sleeping is default in close state before leaving factory, so users must

set

by HXJZ-871 software to set the awakening mode to hardware awakening or interface awakening. Users can

also tell us to set in advance.

If users use HXJZ-871 with the sleeping function, but hope not to apply the sleeping function, the users
can

set by HXJZ-871 software to set for no-sleeping state or make HXJZ-871 pin 5 to connect the ground in the

mode of hardware awaken.

HXJZ-871 parameters setting

HXJZ-871 have one interface of

TTL、

RS232、

RS485, You must specify the interface when you buy.

HXJZ-871 main parameters: COM baud rate and verify,RF baud rate, Channel and frequency。You can

change these parameters by our RF Module soft. When RF baud rate is faster than COM baud rate,One frame

Can transmit limitless data. When RF baud rate is not faster than COM baud rate

One frame Can transmit

255 bytes most.

You can set the rate according your need.

The general Power supply is 5V DC.

Two HXJZ-871 communicate must have condition as follow:

1.Their channels (i.e. frequency) are same.

2.Their RF rates are same.

3. RF Module Com baud rate and verify is agree with its equipment or PC that it connects with.

Parameters default value:

Channel NO.:1

Interface speed rate:9600BPS

Interface verify:none

Speed rate in air:2400BPS
