HXJZ-862 Mini Power Wireless Module User’s Manual
Channel and frequency list
Channel Frequency Channel Frequency
1 428.0028MHZ 5 432.1685MHZ
2 429.0012MHZ 6 431.5020MHZ
3 433.3020MHZ 7 430.0764MHZ
4 433.9164MHZ 8 434.5308MHZ
Technical specification of HXJZ-862
Modulation mode: FSK
Working frequency: 428---433MHZ
Transmission power: ≤ 100mW
Receiving sensitivity: -110dBm
Receiving current: <11mA/TTL，<11mA/RS485，<16 mA/RS232
Channel speed rate: 1200/2400/4800/9600/19200 Bit/s User can Choose one
Interface speed rate: 1200/2400/4800/9600/19200 Bit/s User can Choose
one Change time for receiving and sending: <10ms
Interface data format: 8E1/8N1/8O1
Power supply: 5±0.5V（RS232/RS485） ，2.7--3.3V (TTL) DC
Working temperature: -20℃～65℃
Working humidity: 10%～90% relative humidity without condensation
Dimension: 47mm*33mm*14mm（not include antenna）
Attachable Communication with other Model: HXJZ-862/JZ863/JZ864/JZ865/JZ866
Model and name
JZ 862 -T -U
-U:USBpower
T：TTL interface
2：232 interface
4：485 interface
Nakedboardno
Company
