2-SPEED TRANSMISSION SET (Clutch Type)

#35015 NITRO Z-10

INSTRUCTIONS

* This professional two speed transmission is only for all Nitro Z-10 Car Kits. (Not for Nitro OB-4)

4 X 4mm
Set Screw

NITRO Z10 ASSEMBLY OF THE TWO SPEED GEAR

(45T GREEN and 41T PINK)

35952
45T
Spur Gear
( Green)

35322
1st Gear Carrier
(One-Way)

35953
41T
Spur Gear
( Pink )

35321
2nd Gear
Clutch Bell
( Ball Bearing )

* Screw the M2x10mm screw
into the bottom and back off
5 turns.

M2x10
Screw

M2x10
Screw

6

7

* Apply Screw Glue.

* Apply Screw Glue.

3

35956
Main Shaft

Scr

ew

G

lu

e

Scr

ew

G

lu

e

* Assembly the 1st gear carrier
as shown.

35324
Clutch Shoe
Holder

Adjusting
Hole

Sand Paper

* Use a 500grit sand paper on a flat
surface to sand the shoe flat.

Desk

* Insert the brake disc
before assembly.

38055
Brake Disc
Mount

38050
Pulley
Mount

38050
Pulley
Mount

37050
Pulley
Mount

37410
2x8.8mm
Pin

37410
2x8.8mm
Pin

37660
15T
Pulley

35316
5x8x0.8mm
Washer

35316
5x8x0.8mm
Washer

37430
5x11mm
Ball bearing

38050
20T
Pulley 38050

Pulley
Washer

90021
3mm
E-Ring

* Shown using Z10 parts

* Set the 4x4mm set screw
on the back of the "D" cut.

37450
10x15x4mm
Ball bearing

35326
One-Way
Bearing

Brake Disc

35316
5x8x0.8mm
Washer

35933
2.6 X 3mm
Flat Head
Screw

35933
2.6 X 3mm
Flat Head
Screw

5

Spring

35329
Spring

35329
M2x10mm
Hex Screw

35329
M2x10mm
Hex Screw

35329
M3x3mm
Set Screw

35329
M3x3mm
Set Screw

35323
Clutch
Shoe

35323
Clutch
Shoe

4

35329
Balance

35329
Balance

* Notice the direction of
the gear as shown.

IMPORTANT!
