Use the parts that come with your kit.) – OFNA Racing 2-Speed, Shoe User Manual
Page 2
5 X 5mm
Set Screw
49
#30170
Brake Joint
30170
Brake Joint
#30200
Center
Diff. Mount
(Rear)
#30200
Center
Diff. Mount
(Front)
#30621
7 x 19x 5mm
Ball bearings
#30621
7 x 19x 5mm
Ball bearings
5 X 5mm
Set Screw
Screw
Cement
Screw
Cement
*Use the ball bearings
that come with your car.
3 x 3mm
Set Screw
#33171
Brake Lever
Leave 0.5 mm
3 x 10mm
Tapping Screw
#30211
Plastic
Pushing
#30210
Brake Cam
30220
Center Plate
#30180
Brake Pads
#30190
Brake Disc
3 x12mm
Screw
Screw
Ceme
nt
To Front
*Use the parts comes
with your kit.
(Use the parts that come with your kit.)
8
7
9
ASSEMBLY OF THE 2 SPEED TRANSMISSION INTO CENTER MOUNT
* Large gear to front.
#
