OFNA Racing JL .21 Pro - Manual (Page 2)

52316
52303
52302
52990 52305
52312
52308
52307
52306
52313
52317
52311
52318 52314 52930
52309 52301 52304
52900 10330 52315
52310
JL .21 PRO ENGINES
PART #52207
TECHNICAL DATA
•Cubic Capacity.............3.49cc •Rpm............................37000
•Stroke..........................16.26mm •Hp...................................3.4
•Bore............................16.80mm •Weight..........................300gr
OFNA DESCRIPTION RETAIL OFNA DESCRIPTION RETAIL
10330 COLLET, FLYWHEEL INSERT.12/.21 2.95 52310 HEAD SHIM JL .21 0.2mm 1.95
52181 BALL CAP, THROTTLE 5.95 52311 SEALS,SILICONE MANIFOLD JL .21 9.95
52259 MAIN NEEDLE ASSEMBLY 14.95 52312 O RING CARB BODY JL .21 1.95
52260 MAIN NEEDLE 3.95 52313 WRIST PIN JL .21 2.95
52274 WASHER, MAIN NEEDLE SEAT UPPER 1.95 52314 REAR BACK PLATE JL .21 BLACK 7.95
52275 NIPPLE FUEL SUPPLY BRASS 7.95 52315 SCREW, REAR COVER 3x8mm JL .21 1.95
52276 WASHER, MAIN NEEDLE SEAT LOWER 1.95 52316 SCREW, HEAD 3.5x16mm JL .21 4PC 2.95
52300 THROTTLE BOOT .21-32 FORCE 2.95 52317 CARB LOCKING PIN JL .21 3.95
52301 BALL BEARING, REAR JL .21 24.95 52319 CARB BODY FOR JL .21 PRO 34.95
52302 HEAD BUTTON JL .21 TURBO 34.95 52321 LOW END NEEDLE FOR JL .21 PRO 4.95
52303 HEAD, JL .21 PRO BLACK 71.95 52322 MAIN NEEDLE HOUSING JL .21 5.95
52304 CRANKCASE JL .21 59.95 52322 MAIN NEEDLE HOUSING JL .21 5.95
52305 CARBURETOR COMPLETE JL .21 89.95 52323 IDLE SCREW JL .21 PRO 2.95
52306 PISTON/SLEEVE JL .21 PRO 149.95 52324 DRUM BARREL JL .21 PRO 9.95
52307 PISTON/SLEEVE COMPLETE JL .21 179.95 52900 BEARING, FRONT FORCE .21-.32 5.95
52308 CONNECTING ROD JL .21 27.95 52930 SEAL, REAR COVER 1.95
52309 CRANKSHAFT SG JL .21 89.95 52960 SEAL, MAIN NEEDLE 0.95
52990 G-CLIPS, 2 PCS. 1.95
52207 JL 21 PRO PARTS LIST
52960
52323
52319
52324
52300
52181
52960
52321
52276
52275
52274
52322
52960
52260
