CLIFFORD AvantGuard III User Manual

Page 36

Table of user-selectable features: 1 chirp = OFF, two chirps = ON

Feature Select

Column 1

1st latched

Column 2

2nd latched

Column 3

3rd latched

Column 4

4th latched

Column 5

5th latched

Column 6

6th latched

Row 1

1st momentary

Sound 1: on/off
info on page 26

Add new remote to channel 1

info on page 15 NOTE 1

AutoLock: on/off

info on page 25

AutoArming: on/off

info on page 18

NightVision: off/on but no

post-parking illumination/on

(1/2/3 chirps) info on page 23

Use this remote to activate which

memory seat position?

info on page 20 NOTE 6

Row 2

2nd momentary

Sound 2: on/off
info on page 26

Add new remote to channel 2

info on page 15 NOTE 1

AutoUnLock: on/off

info on page 25

AutoArm & Lock: on/off

info on page 18

Post-parking and remote headlight

duration: 1sec–2.0min (30sec)

info on pages 15 and 23 NOTE 5

Door ajar warning/delayed

courtesy lights

this feature is for installers only

Row 3

3rd momentary

Sound 3: on/off
info on page 26

Add new remote to channel 3

info on page 15 NOTE 1

FACT: on/off

info on page 23

15-second entry delay: on/off

info on page 18

SilentNight: on/off

info on page 23

RPM-activated AutoLock: on/off

info on page 25

Row 4

4th momentary

Sound 4: on/off
info on page 26

Add new remote to channel 4

info on page 15 NOTE 1

AutoActivate channel 4 timed

accessory upon remote arming
this feature is for installers only

AutoStart: battery mode/

temperature mode/dual mode/off

(2/3/4/1 chirps) NOTE 3

✱ Channel 4 timer: 1sec-2.0min

(30sec) info on page 15 NOTE 5

RPM programming

this feature is for installers only

Row 5

5th momentary

Sound 5: on/off
info on page 26

Add new remote to channel 5

info on page 15 NOTE 1

QuietChirps: on/off

info on page 26

Siren duration: 60/30 seconds

(1/2 chirps) info on page 26

Channel 4 output type:

pulsed/timed/latched

this feature is for installers only

Lock pulse duration: 3sec/1sec

this feature is for installers only

Row 6

6th momentary

Sound 6: on/off
info on page 26

Erase all channels

info on page 26 NOTE 2

Long-term chirp silencing: on/off

info on page 26

Set a new secret valet code

info on page 20 NOTE 4

NOT USED

Diesel/gasoline fuel injection

this feature is for installers only

✱ WARNING: If the system automatically closes the power windows and sunroof when you remotely arm, DO NOT CHANGE THIS SETTING: It requires installer-only adjustment. Changing the duration may cause damage.

The grey cells indicate a feature that requires programming only by a qualified installer. DO NOT change any of the installer-only settings.

NOTE 1:

Transmit the appropriate channel of the new remote control. You will hear the

same number of chirps as the channel selected (e.g., 3 chirps for channel 3) to confirm
programming of that channel.

NOTE 2:

When you hear one chirp, all remote control channels will have been erased

from the system memory. You must now add the new and/or existing remote controls
to the system (i.e., program channels 1–5 of each remote control).

NOTE 3:

Press button 4 to turn AutoStart off (1-chirp confirmation), press button 1 to

select AutoStart battery mode (2-chirp confirmation), press button 2 to select AutoStart
temperature mode (3-chirp confirmation), press button 3 to select AutoStart dual mode
(4-chirp confirmation). This selects the AutoStart mode. To engage AutoStart, you will
later transmit channel 10 while the system is disarmed (see page 29 for more information).

NOTE 4:

Immediately flip the switch to its latched position, then:

a. Enter the new code that you wish to use. The system will sound the same number

of chirps as the digit you choose when you move the switch to the latched side
(e.g., if the first digit is 4, you’ll hear four chirps when you press the latched side).

b. Make sure to return the switch to its center position when complete.

c. Wait 3 seconds until you hear 2 chirps, confirming the new code has been accepted.

d. Turn the ignition off. You’ll hear 3 chirps and the LED will turn off.

e. VERY IMPORTANT: You must immediately test your new valet code: Turn

the ignition on, enter your new code, then flip the switch to its latched position.
The LED will illuminate. If it does not, the new code you programmed and the one
you just entered do not match. The system has reverted to the previous code.

NOTE 5:

The timer starts as soon as you select this feature. When the duration you wish

has been reached, press remote control button 1. You’ll hear two chirps to confirm the
new duration.

NOTE 6:

After you select this feature, take the remote control you will be using and

press either button 1, 2, 3 or 4 to select the vehicle’s memory seat position 1, 2, 3 or 4,
respectively, that has been set up for your driving comfort. For a second driver, select
this feature, take the other remote control and press either button 1, 2, 3 or 4 to select
the vehicle’s memory seat position 1, 2, 3 or 4, respectively, that has been set for the
secondary driver. You may do this with up to four different remote controls and up to
four different memory seat positions, in any combination.
