Woo Audio WA7 Fireflies - Manual (Page 12)

©2014 WOO AUDIO tm Inc. All rights reserved. www.wooaudio.com Rev 1.0. May, 2014 12
Specifications
Model: WA7tp
Power supply External linear vacuum tubes power supply
Tubes used Matched pair 12AU7 as rectifiers
Mains Supply: 100-120V, 220-240V, 50/60Hz, user selectable
Power consumption 25W max
Mains Supply: 100-120V, 220-240V, 50/60Hz, user selectable
Fuse Slow blow fuse, 400mA@115V, or 300mA@230V
PSU body finish Anodized Aluminum in Black and Silver
Dimension: PSU: 4.8" L x 4.8" W x 5.1" H with glass
Weight: PSU - 5.3 lbs / 2.4kg, Glass - 3.3 lbs / 1.5 kg
Woo Audio is committed to continuously improve its products.
Features and specifications are subject to change without notice
