9
BIT
STORAGE
FEATURES
KNOW YOUR DRILL
See Figure 1.
The safe use of this product requires an understanding of
the information on the tool and in this operator’s manual as
well as a knowledge of the project you are attempting. Before
use of this product, familiarize yourself with all operating
features and safety rules.
BIT STORAGE
Bits provided with the drill can be placed in the storage
areas, located on the base of the drill.
DIRECTION OF ROTATION SELECTOR
(FORWARD/REVERSE/CENTER LOCK)
Your drill has a direction of rotation (forward/reverse/center
lock) selector located above the switch trigger for changing
the direction of bit rotation. Setting the switch trigger in the
OFF (center lock) position helps reduce the possibility of
accidental starting when not in use.
KEYLESS CHUCK
The keyless chuck allows you to hand-tighten or release the
drill bit in the chuck jaws.
MAGNETIC BIT HOLDER
The magnetic bit holder extends the reach of the bit and
holds the bit and screws until you are ready to drive them.
Storage is located on the front of the drill’s base.
MAG TRAY ™
The Mag Tray ™ conveniently stores screws or other small
parts.
QUICK MODE SELECTOR
The Quick Mode Selector allows you to quickly switch from
drive mode to drill mode.
TORQUE ADJUSTMENT RING
Your drill has a 24-position clutch. The torque adjustment
ring can be turned to select the right amount of torque for
your application.
TWO-SPEED GEAR TRAIN
The two-speed gear train is designed for drilling or driving
at
LOW (1) or HIGH (2) speeds. A slide switch is located
on top of your drill for selecting either LOW (1) or HIGH (2)
speed.
VARIABLE SPEED
The variable speed switch trigger delivers higher speed
with increased trigger pressure and lower speed with
decreased trigger pressure.
ASSEMBLY
UNPACKING
This product has been shipped completely assembled.

Carefully remove the tool and any accessories from the
box. Make sure that all items listed in the packing list are
included.
 Inspect the tool carefully to make sure no breakage or
damage occurred during shipping.
 Do not discard the packing material until you have
carefully inspected and satisfactorily operated the tool.
 If any parts are damaged or missing, please call
1-800-525-2579 for assistance.
PACKING LIST
Drill
Battery Packs (2)
Charger
Bits (2)
Magnetic Bit Holder
Operator’s Manual
WARNING:
If any parts are damaged or missing do not operate
this tool until the parts are replaced. Failure to heed this
warning could result in serious personal injury.
WARNING:
Do not attempt to modify this tool or create accessories
not recommended for use with this tool. Any such
alteration or modification is misuse and could result in a
hazardous condition leading to possible serious personal
injury.
WARNING:
To prevent accidental starting that could cause serious
personal injury, always remove the battery pack from the
tool when assembling parts.
