Model lv-30 & lv-30h – Clarke LV-30H User Manual
Page 11
Clarke
®
Operator's Manual LV-30
Page 11
Ref.
Ref.
Ref.
Ref.
Ref. Part No.
Part No.
Part No.
Part No.
Part No.
Description
Description
Description
Description
Description
Qty.
Qty.
Qty.
Qty.
Qty.
46
215110
Label - Caution, Spanish
1
47
215103
Label - Caution
1
48
962158
Screw - 5/16 - 18 x 7/8 Hex
4
*
962324
Screw - 5/16-18 x 1.5 Hx Hd
4
49
30521A
Bag - Filter Plain
1
50
765044
Knob - Throttle Control - Svc. Only
1
51
34267A
Gasket - Muffler Mtg. (Honda Only)
1
52
215104
Label - Warning
1
53
215106
Label - Warning
1
55
62812A
Extension Assembly Honda
1
57
755721
Nipple - 1/4-18 Short
1
58
822806
Elbow - 90° Street
1
59
170266
Coupling - 1/4 NPT
1
60
ref.
Drain Plug (part of engine)
1
61
85702A
Screw - 1/4-20 x 1 5/8 Hex St. Cap
2
62
85701A
Screw - 1/4-20 x 1 1/2 Hex St. Mach
2
63
764541
Hook - Bag Right
1
64
766740
Pin - Locking
2
65
920284
Nut - 1/4-20 Stop
4
66
763740
Grip - Handle
2
67
761340
Brace - Handle
1
68
764540
Hook - Bag Left
1
69
763940
Handle
2
70
763701
Grip - Handle
1
71
761140
Bushing - Handle
1
72
962009
Screw #10-24 x 1 1/4 Rd St. Mach
1
73
763840
Guide - Handle
1
74
763946
Handle - Upper
1
75
766744
Pin - Locking
1
76
Plate - Serial
1
77
930112
Rivet - 1/8 Pop
4
78
805160
Label - Inspection
1
79
763264
Frame Assembly- Small Wheel
1
79a 763263
Frame Assembly - Large Wheel
1
80
920208
Nut - 1/4-20
8
81
920110
Nut - 5/16-18 Elastic Stop
4
82
980651
Washer - 5/16 Plain
4
83
925006
Pin - 1/8 x 1 1/4 Lg. Cotter
2
84
980679
Washer - 13/16 x 1 1/4 x 1/8 Flat
2
85
768244
Spacer - Wheel
2
86
769701
Wheel - Assembly
2
87
194446
Cap Hub w/Retainer
2
88
765141
Label - Caution
1
89
769740
Wheel - Large
2
90
761541
Hub - Cap
2
91
70651A
Label, Div. of ALTO
1
NOTE: indicates a change has been made since the last
publication of this manual.
Clarke
®
Model LV-30 & LV-30H
Model LV-30 & LV-30H
Model LV-30 & LV-30H
Model LV-30 & LV-30H
Model LV-30 & LV-30H
Parts List - 9/03
Parts List - 9/03
Parts List - 9/03
Parts List - 9/03
Parts List - 9/03
* Indicates parts that are for the LV 30H (Honda engine) only.
* Indicates parts that are for the LV 30H (Honda engine) only.
* Indicates parts that are for the LV 30H (Honda engine) only.
* Indicates parts that are for the LV 30H (Honda engine) only.
* Indicates parts that are for the LV 30H (Honda engine) only.
Ref.
Ref.
Ref.
Ref.
Ref. Part No.
Part No.
Part No.
Part No.
Part No.
Description
Description
Description
Description
Description
Qty.
Qty.
Qty.
Qty.
Qty.
1
920196
Nut 1/2 - 13 Hex Jam
2
2
980626
Washer - 1/2 Lock
2
3
760842
Bracket - Caster Support Asm.
2
4
766742
Pin Assembly - Disconnect
2
5
769744
Caster - Front Support
2
6
60050A
Cover - Intake
1
7
762043
Clamp - Rear R.H.
1
8
768542
Scraper - R.H.
1
9
15711B
Housing Assembly - Intake
1
10
980646
Washer - 1/4"
15
11
920180
Nut - Acorn 1/4 - 20
7
12
760741
Blade - Door
1
13
762047
Clamp - Door Blade
1
14
962483
Screw #10-24 x 5/8
1
15
980982
Washer #10 x 1/2
1
16
763945
Handle - Lower
1
17
768242
Spacer - Handle
1
18
70462A
Label
1
19
920296
Nut - #10-24 Elastic Stop
16
20
84808A
Screw #10-24 x 3/4 Rd. Hd.
10
21
962109
Screw #10-24 x 5/8
4
22
762045
Clamp - R.H. Shield
1
23
762046
Clamp - L.H. Shield
1
24
767841
Shield
2
25
768543
Scraper - L.H.
1
26
762044
Clamp - Rear L.H.
1
27
930086
Rivet - 3/16 x .450
4
28
682006
Lid Clamp Assembly
2
29
763444
Gasket - Intake Hsg. Flange
1
30
66909A
Retainer Assembly
1
31
66908A
Retainer Assembly
1
32
66907A
Retainer Assembly
1
33
763443
Gasket - Impeller Housing
1
34
930113
Rivet - Pop 1/8
5
35
962241
Screw - #10-24 x 1/2
4
36
962747
Screw - 3/8-24 x 3/4 Nylok Hex Hd
1
*
962867
Screw 7/16 - 20 x 1 Hex Head
1
37
980013
Washer - Clamp Honda & Tecumseh
1
38
35210B
Housing - Impeller
1
39
764841
Impeller Honda & Tecumseh
1
40
962593
Screw - 1/4-20 x 3/8 Nylok
1
41
962603
Screw - 5/16 - 24 x 1 1/4 Hex.
4
42
766664
Plate Assembly - Flange
1
43
980652
Washer - 5/16 Standard Lock
4
44
915570
Key - 1/4 x 1/4 x 2 1/4 Square
1
45
50035B
Engine - Gas 5.5 hp Tecumseh
1
*
53808A
Engine- Gas 5.5 hp Honda
1
Optional Accessories:
760641 Bag Support Assembly
764140 Kit, Intake 6" x 10' Hose
764141 Kit, Intake 4" x 10' Hose
