OPERATION
CHARGING A HOT BATTERY PACK
When using a tool continuously, the battery pack may be-
come hot. A hot battery pack may be placed directly onto
the charger port but charging will not begin until the battery
temperature cools to within acceptable temperature range.
When a hot battery pack is placed on the charger, the red
LED will begin flashing and the green LED will be off. When
the battery pack cools, the charger will automatically begin
charging.
LED FUNCTIONS
See Figure 1, page 7.
BATTERY PACK
RED
LED
GREEN
LED
ACTION
Power On
Alimentation
Corriente
Power On
Without battery pack
ON
OFF
Ready to charge battery pack.
Testing
Evaluer
Evaluar
Testing
Hot battery pack
Flashing OFF
When battery pack reaches cooled temperature, charger begins fast charge mode.
Cold battery pack
Flashing OFF
When battery pack reaches warmed temperature, charger begins fast charge mode.
Deeply discharged
Flashing OFF
Charger conditions battery until normal voltage is reached, then begins fast charge
mode.
Defective
Defectueux
Defectuoso
Defective
Defective
Fading
OFF
Battery pack or charger is defective.
• If defective, try to repeat the conditions a second time by removing and reinstalling the battery pack. If the LED status repeats a
second time, try charging a different battery.
• If a different battery charges normally, dispose of the defective pack (see Maintenance section).
• If a different battery also indicates “Defective,” the charger may be defective.
Charging
En charge
Cargando
Charging
Fast charging
ON
Flashing Battery is being charged.
Charged
Charge max.
Completo
Charged
Battery full
OFF
ON
Fast charging is complete; charger maintains charge mode.
Energy Save
Mode
Mode d’économie
d’énergie
Modo de ahorro
de energía
Energy Save Mode
Battery full /
Energy Save mode
OFF
Fading
Battery pack is fully charged and charger is in Energy Save mode.
CHARGING A COLD BATTERY PACK
A cold battery pack may be placed directly onto the charger
port but charging will not begin until the battery temperature
warms to within acceptable temperature range. When a cold
battery pack is placed on the charger, the red LED will begin
flashing and the green LED will be off. When the battery
pack warms, the charger will automatically begin charging.
This product has a Three-year Limited Warranty.
For Warranty details go to www.ryobitools.com
NOTE: MAINTENANCE INFORMATION BEGINS ON PAGE 6 AFTER FRENCH
AND SPANISH LANGUAGE SECTIONS. ILLUSTRATIONS START ON PAGE 7.
