Ryobi A113TS2 - Manual

English
WARNING:
To reduce the risk of injury, do not attempt to use this
product until you have read thoroughly and understand
completely this Operator’s Manual and the Operator’s
Manual for the Tile Saw.
UNPACKING
This product requires assembly.
n
Carefully remove the product from the box. Make sure
that all items listed in the packing list are included.
WARNING:
Do not use this product if any parts on the Loose Parts List
are already assembled to your product when you unpack
it. Parts on this list are not assembled to the product by
the manufacturer and require customer installation. Use
of a product that may have been improperly assembled
could result in serious personal injury.
n Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
n Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
n If any parts are damaged or missing, please call
1-800-525-2579 for assistance.
WARNING:
If any parts are damaged or missing do not operate this
tool until the parts are replaced. Use of this product
with damaged or missing parts could result in serious
personal injury.
LOOSE PARTS LIST
See Figure 1.
TOOLS NEEDED
See Figure 2.
ASSEMBLING THE STAND
See Figures 3 - 7.
n
Lay outside support bracket, on a flat surface. Place inside
support bracket on top of outside support bracket with
the top rails facing each other, as shown.
n Insert stand legs into the support brackets. Angled ends
of stand legs should face away from each other so they
resemble a “V”. Align holes for hardware.
n Place hinge A between leg assembly on right side. Repeat
with hinge B on left side.
n Carefully align holes in legs and hinge. Install hardware
through holes as shown.
n Using wrenches, tighten hardware securely.
n Place stand on level ground and line up rails under tile
saw table with brackets on stand. Position tile saw onto
stand.
n Be sure the tile saw is on level ground and the stand is
sturdy before use.
CALIFORNIA PROPOSITION 65
WARNING:
This product may contain chemicals, including lead,
known to the State of California to cause cancer, birth
defects or other reproductive harm.
Wash hands after
handling.
990000891
4-14-14 (REV:01)
OPERATOR’S MANUAL
TILE SAW STAND
A113TS2
FOR USE ONLY WITH THE RYOBI WS722 TILE SAW
This product has a Three-year Limited Warranty.
For Warranty details go to www.ryobitools.com
SAVE THESE INSTRUCTIONS
ONE WORLD TECHNOLOGIES, INC.
1428 Pearman Dairy Road, Anderson, SC 29625
Phone 1-800-525-2579
www.ryobitools.com
