FieldPro-E Owner’s Manual EN-6
SCOUT ™ Quick Start Guide
Step 1
Install Transmitter Batteries and Charge Receiver
1 1.. Plug the AC Adapter into a
220VAC outlet.
2 2.. Connect the AC Adapter to the
Receiver Cradle.
3 3.. Put the Receiver on the Receiver
Cradle as shown in figure 3. The
light on the Receiver glows red
while charging, and glows green
when fully charged. If you don’t
see a light glowing, try turning the
Receiver around on the Cradle.
4 4.. Install Transmitter Batteries:
• Remove the battery cover from
the back of the Transmitter.
• Insert 3 AAA alkaline batteries
(oriented as shown in battery
compartment).
• Replace the battery cover.
• When the batteries are put in, the
Scout Transmitter is in battery
conservation mode; press any
button to activate the transmitter.
2 2
4 4
Note battery polarity when installing batteries.
to Receiver Cradle
1 1
SCOUT
™
Quick Start Guide
To maintain maximum range,
keep the Transmitter antenna
away from all magnets (there is
a magnet in the Charging
Cradle). Exposure to a magnet
may permanently diminish
range.
3 3
LED LIGHT
+ + — — + +
— — + + — —
