OVERVIEW
[1] Adaptor Housing
[2] Eyepiece Mount (Bushing)
[3] Eyepiece Thumbscrew
[4] MiNi-14 Housing
[5] Device Retainer Arms
[6] Weaver Base
PRODUCT BREAK-DOWN Figure 1 Note:
With the enclosed set of (7)
bushings the Day/Night
Adaptor will fit on the
eyepiece optics with an
outside diameter ranging
from 1.5-1.75 inches.
