5 NIGHT VISION
FEATURES
Long range observation under very low light conditions
Able to withstand high caliber recoil (including 50 BMG)
Illuminated dual color MIL-DOT reticle with brightness control
High resolution throughout the field of view
Specially designed multi-coated HD optics with super light transmission
Internal optical focusing system increases stability & precision
Manual gain control
Bright source protection
Quick release dual-clamp mounting system
Waterproof nitrogen purged construction
State-of-the-art impact resistant housing
Lightweight
OPERATION
!WARNING!
Prior to installing the battery make sure the day time protective cover is fitted over
the lens. Excessive light can damage intensifier tube and void warranty.
1. BATTERY INSTALLATION
The Magnus 790 uses (2) AA batteries. Loosen the retaining screw on the battery
compartment cover (fig 1-10) and install the batteries according to the diagram on the
side of the battery compartment housing.
Reinstall the battery compartment cover and thread the retaining screw finger tight. Be
careful not to over tighten or cross-thread the screw.
To avoid damage, leakage or corrosion, remove and store batteries when not in use.
