- 8 -
REAR PANEL DISPLAY – INPUTS & OUTPUTS
INPUTS (Located at rear of unit): The MD 108 has two antenna inputs, labeled
A1 and A2. These are controlled by the front panel input selector knob (Knob on
left side of front plate). The inputs D1 and D2 are for future use.
OUTPUTS (Located at the rear of the unit): The MD 108 T uses high grade XLR
connectors for
balanced output in a fully balanced system. Unbalanced output is
handled through the high quality gold plated WBT RCA connectors.
