M2tech – M2TECH hiFace Dac User Manual

Page 25

Text mode
Original mode

hiFace DAC
384

/32bit digital-TO-ANALOG CONVERTER

REVISION 1.1 – MAY 2013

M2Tech

www.m2tech.biz

7.2. Winamp and MediaMonkey

These two players are actually the same player with different skins, so they can share the
same plug-ins. A freeware plug-in for Kernel Streaming by Steve Monks is available on the
Internet (

http://www.stevemonks.com/ksplugin/

) that can be used to enable Kernel

Streaming operation with these players.
Download the zip file, extract the dll file and copy it into the Plugins folder inside Winamp
main folder.
With hiFace DAC connected, right-click on Winamp and select Display/Select Plug-ins.
The Preferences window of Winamp will open (see figure 20).

Figure 20

Go to Plug-in/Output and select “M2Tech Audio 2.0 Output”. Then click on Configure
button. Choose HIFACE DAC Kernel Streaming in the output device list (Figure 21).
