3. Connection to the host

Please refer to section 2, “Front Panel Description”.

Connect the “B” plug of a 2.0 USB A-B cable to the USB connector (Figure 1, 3) of hiFace
Evo.

Connect the “A” plug of the cable to a 2.0 USB port of your computer.

Connect a 9V power supply or a 7.2V/10.8V lithium battery, or a 9V alkaline battery to the
supply connector (Figure 1, 1) of hiFace Evo. The power indicator (Figure 1, 6) will lit.

If a driver hasn’t been installed on your computer, an automatic driver installation wizard
may appear.

Note: If you want to avoid the automatic driver installation, please connect hiFace
Evo to the computer after manually installing the driver (see section 4).
