Assembly Instructions 2/3
STEP 1
Assemble Stretchers (B),
Base (D) to Side Frame (C)
with Head Cap Bolts,
Spring Washers and Flat Washers.
(See figure 1)
STEP 2
Flat Washer
Spring Washer
Head Cap Bolt
Figure 1
IMPORTANT
* Do not tighten up all the screws until each part is properly assembled.
* You should keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future.
* Use a soft cloth between these parts and the floor.
B
B
C
C
D
Remove the drawer,
then place Cabinet (A)
upside down on a soft cloth.
A
