Assembly Instructions
STEP 1
IMPORTANT
* Do not tighten up all the screws until each part is properly assembled.
* You should keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future.
* Use a soft cloth between these parts and the floor.
Attach Stretcher (E) and (F) to
Side Frame (C) with Head Cap Bolts (long)
and Cross Dowels.
Attach Side Frame (D) to the unit
with Head Cap Bolts and Cross Dowels.
STEP 2
Attach Seat (B) to the
unit with Wood Screws.
Attach Backrest (A) to the
unit with Head Cap Bolts (short)
and Head Cap Bolts.
C
D
F
Wood Screw
Head Cap Bolt
Head Cap Bolt (short)
Head Cap Bolt (long)
Cross Dowel
