Assembly Instructions
STEP 3
Figure 1
IMPORTANT
* Do not tighten up all the screws until each part is properly assembled.
* You should keep Key Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future.
* After assembly, item must be level to work properly. Use the included adjustable levelers to level.
Turn the table to its’ upright position.
Cover the umbrella hole with Cover.
(See figure 2)
To level the table, adjust the
adjustable levelers on
the bottom of legs.
(See figure 3)
Figure 2 Figure 3
Place Top (A)
upside down on a soft cloth.
Insert all Bolts into the pre-drilled holes
of Top (A). (See figure 1)
Attach unit from Step 1 to Top (A)
with Flat Washers (large), Spring Washers,
Nuts and Nut Caps.
Nut Cap
Flat Washer (large)
Spring Washer
Bolt
A
Nut
STEP 2
B
C
Attach Legs (B) to Stretchers (C)
with Flat Washers (small), Bolts
and Bolt Caps.
STEP 1
Bolt Cap
Bolt
B
B
B
C
Flat Washer (small)
