The Brute Elite 125

Figure 3. Dimensional Drawing.

Cond. Hydronic DHW

2nd

Gas

Hydronic DHW

2nd

Outlet

Return

Inlet

Return

Supply

Supply

Outlet

Supply

3/4"

3/4"

1/2"

3/4"

1/2"

3/4"

1/2"

3/4"

PVC

copper

NPT

copper

NPT

NPT

NPT

copper

1.8 Dimensions
