THERMOSTAT ADJUSTMENT
160°F
Control 180°F
Control
Figure 2
The thermostat dial is set to its lowest temperature setting when shipped from the factory.
Remember that lower temperature settings are more energy efficient. Adjust the temperature
by turning the thermostat dial. It is suggested that the starting point setting not be greater than the
”
“ or “ “mark on the thermostat dial (approximately 120°F [48.9°C]) V as indicated below.
Rotate the thermostat dial clockwise
to decrease the temperature setting. Rotate the
thermostat dial counter-clockwise
to increase the temperature setting. Adjust the dial
until the minimum acceptable temperature is achieved (See figure 2 above for approximate
temperature settings).
160°F Control
180°F Control
Figure 3
The thermostat dial is set to its lowest temperature setting when shipped from the factory.
Remember that lower temperature settings are more energy efficient. Adjust the temperature
by turning the thermostat dial. It is suggested that the starting point setting not be greater than the
“
” mark on the thermostat dial (approximately 120°F [48.9°C]) as indicated below. Rotate the
thermostat dial counter-clockwise
to decrease the temperature setting. Rotate the
thermostat dial clockwise
to increase the temperature setting. Adjust the dial until the
minimum acceptable temperature is achieved (See figure 3 above for approximate temperature
settings).
