SECTION 2: LOOSE PARTS
The grass catcher kit is shipped with following loose parts in the carton. Please remove all loose parts, including the
hardware pack, from the carton before discarding it. Compare with Figure 1 to check that all parts were included.
Note that the kit and the hardware pack contain extra items which are not used on your unit.
Figure 1
Discharge
Assembly
Grass Bag
Grasscatcher Cover
Mounting
Support Tube
(attached to cover)
Assembly
Bracket
Chute
Chute Stop
Bracket
Carriage Bolt
Lock Nut
Blades
