Clarion DB455MC - Manual (Page 23)

24
DB455MC
280-8137-00
English
FM Tuner
Frequency Range: 87.9 MHz to 107.9 MHz
Usable Sensitivity: 9 dBf
50dB Quieting Sensitivity: 15 dBf
Alternate Channel Selectivity: 70 dB
Stereo Separation (1 kHz): 35 dB
Frequency Response (±3 dB): 30 Hz to 15 kHz
AM Tuner
Frequency Range: 530 kHz to 1710 kHz
Usable Sensitivity: 25 µV
CD Player
System: Compact disc digital audio system
Usable Discs: Compact disc
Frequency Response (±1 dB): 10 Hz to 20 kHz
Signal to Noise Ratio (1 kHz): 100 dB
Dynamic Range (1 kHz): 93 dB
Harmonic Distortion: 0.03%
MC mode
HQ: Approximately 130 minutes, 32 tracks
(4 minutes for each)
LP: Approximately 173 minutes, 43 tracks
(4 minutes for each)
10. SPECIFICATIONS
Audio
Maximum Power Output: 208 W (52 W
✕ 4 ch)
Continuous Average Power Output:
17 W ✕ 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD
Bass Control Action (100 Hz): +14 dB, –14dB
Treble Control Action (10 kHz):
+14dB, –14dB
Line Output Level (CD 1 kHz): 1.8 V
General
Power Supply Voltage:
14.4 V DC (10.8 to 15.6 V allowable), negative
ground
Current Consumption: Less than 15 A
Speaker Impedance: 4
Ω (4 Ω to 8 Ω allowable)
Weight / Source unit: 2.86 lb. (1.3 kg)
Weight / Remote control unit:
1.41 oz. (40 g) (including battery)
Dimensions / Source unit:
7" (Width)
✕ 2" (Height) ✕ 6-1/8" (Depth)
[178 (W) ✕ 50 (H) ✕ 155 (D) mm]
Dimensions / Remote control unit:
1-3/4" (Width) ✕ 4-5/16" (Height) ✕ 7/16"
(Depth)
[44 (W)
✕ 110 (H) ✕ 11 (D) mm]
Notes:
• Specifications and design are subject to change without notice for further improvement.
