Ex SERiES
compAcT TRAcToRS
*as rated by engine manufacturer
†See your local Cub Cadet Yanmar Independent Dealer for warranty details.
Additional attachments are available. Please ask your dealer or visit cubcadetyanmar.com for more information.
Important: Front loader is required to maximize backhoe capabilities. When using the CB75 backhoe, the stabilizers
and front loader bucket must be lowered until all weight is removed from the tractor tires. For transport, it is
recommended that at least 25% of the total tractor weight remains on the front axle of the tractor. Installing
the Cub Cadet Yanmar Model CL300 loader will meet this weight-distribution requirement.
This brochure is for advertisement purposes only. The product depictions are not meant to be used or relied upon as
a substitute for the safety and use information that is published in the respective operator’s manual. Before operating
the machine, read, understand and follow all instructions in the manual and on the machine. Specifications and
programs are subject to change without notice. Images may not reflect dealer inventory and/or unit specifications.
powERTRAin Ex2900 Ex3200
gross HP 28.7 HP* diesel 32 HP* diesel
Pto HP (Hyd) 22.7 at 2,600 rPm 25.5 at 2,600 rPm
rated rPm 2,600 rPm
bore and stroke 88 x 90 mm
total displacement 100.2 cu. in.
Ignition type Direct injection
Air cleaner Dual dry
lubrication full pressure
Cooling system liquid cooled
radiator fan 7-fin
Number of cylinders 3
cApAciTiES
fuel tank 6.3 gal.
Cooling system 4.7 qt.
engine oil 4.2 qt.
transmission case 5.4 gal.
dRivETRAin
transmission type Hydrostatic
Clutch Dry single
rear differential lock foot pedal operation
2wD/4wD engagement Selectable
final drive bevel gear
brake wet disc
Number of ranges 3
Pto type Continuous live
rear Pto/rPm 540/2,592
mid Pto/rPm 2,100/2,630
mAximUm TRAvEling SpEEd
forward/reverse high 13.2 mph
forward/reverse medium 6.9 mph
forward/reverse low 4.0 mph
HydRAUlicS
type open center
Pump gear
maximum pump capacity 9.9 gPm at 2,600 rPm
Pump capacity (main) 5.6 gPm at 2,600 rPm
Pump capacity (steering) 4.3 gPm at 2,600 rPm
3-point hitch Category 1
Hydraulic control system Position control
3-point lift capacity at 24" behind 1,100 lbs.
4-way loader control valve Standard
Power steering fully hydraulic
dimEnSionS
wheelbase 61"
width 59.1"
overall length w/o 3-pt hitch 109.5"
ground clearance 10"
weight w/roPS 2,495 lbs. 2,500 lbs.
TiRE SizE
front industrial 25" x 8.5" – 14"
rear industrial 15" – 19.5"
front agricultural 7" – 14"
rear agricultural 11.2" – 24"
front turf 25" x 8.5" – 14"
rear turf 13.6" – 16"
RESidEnTiAl/commERciAl
wARRAnTy †
tractor 2-year or 2,000-hour limited warranty
engine/drivetrain 5-year or 2,500-hour limited warranty
cl300 cURvEd Boom loAdER
maximum lift height at pivot point 96"
Dump clearance 77"
reach at maximum height 25"
maximum dump angle 45°
reach w/bucket on ground 67"
maximum rollback angle 25°
Digging depth 4"
overall height in carry position 54"
length of attachment (bucket bottom) 18"
maximum lift height under bucket 91"
loader weight w/o bucket 645 lbs.
bucket width/weight 60"/210 lbs.
bucket capacity 7 cu. ft.
lift capacity at pivot pins,
maximum height
900 lbs.
lift capacity 500 mm forward of the
pivot pins, maximum height
770 lbs.
breakout force at bucket pivot pins 2,500 lbs.
breakout force at 500 mm
forward of the pivot pins
1,825 lbs.
raising time to full height w/o load 4 sec.
lowering time w/o load (power down) 2.5 sec.
Attachment rollback time 2 sec.
Attachment dumping time 1.5 sec.
rated flow 5.6 gPm
relief valve 2,062 PSI
cB75 cURvEd Boom BAckHoE
maximum digging depth 92"
Digging depth (2' flat bottom) 87"
Swing arc 180°
loading height 78"
reach from swing pivot 124"
transport height 81"
bucket rotation 180°
loading reach 43"
transport overhang 45"
undercut 17"
Stabilizer spread (down) 89"
bucket cylinder digging force 2,804 lbs.
Dipperstick cylinder digging force 1,985 lbs.
weight (less bucket) 925 lbs.
operating pressure 2,065 PSI
ramp angle (w/industrial tires) 18°
weight (w/o Power beyond kit) 899 lbs.
weight (subframe and adapter) 342 lbs.
Street pads Standard
bucket options various 9" – 24"
RESidEnTiAl/commERciAl
wARRAnTy †
Attachments 1-year limited warranty
Ex Series Tractor Specifications Ex Series Attachment Specifications
773-04212 Printed in u.S.A. 12/10 © 2011 Cub Cadet Yanmar
