Clarke CAV 26 - Manual (Page 4)

Page -4- Clarke ® American Sanders Operator's Manual - CAV 26
Model CAV 26
Voltage 120 V
Frequency 60 Hz
Power 2400 W (800 x 3)
Ambient Temp -23°F to 86° F
Volume Flow (CFM) 290 (max)
Static Lift (inches H
2
O) 82
Sound Level dB(A) 73
Cord Length (ft.) 36
Tank Volume 26 gal.
Width (in.) 26
Depth (in.) 27
Height (in.) 61
Weight (lbs.) 143
SPECIFICATIONS
INTRODUCTION AND INSTRUCTIONS
The CAV 26 comes fully assembled. It is specifically designed for dry pick-up of fine dust made from grindings of wood
or gypsum. It is mounted on tough rubber wheels, two of which swivel in order to make the machine easy to handle. It
also has brakes to safely stop the machine in place.
NOTE: When performance has declined noticeably, empty tank and clean the filters accordingly.
Figure 2 Figure 1 Figure 3
4
1
2
3
1
2
3
1
2
