2. I
NTRODUCTION
Features
• 6 to 8-channel DMX-512 moving yoke
• Pan: 540° / tilt: 270°
• Variable strobe/shutter
• Color
wheel:
7 colors + white
Rainbow color spin effect
• Rotating gobo wheel:
7 interchangeable, rotating gobos + open
5 metal, 2 dichroic gobos
Gobo wheel spin effect
• Variable motorized dimmer (0 – 100%)
A d d i t i o n a l F e a t u r e s
• Gobo size: 23.5mm outside, 17.5mm image, 0.2mm max thickness
• Round base design for flush mounting
• User-selectable pan/tilt ranges
Pan: 540 °, 360°, 180°
Tilt: 270°, 180°, 90°
• Built-in automatic programs via master/slave
• Built-in sound activated programs via master/slave
• User-selectable 16bit or 8bit pan/tilt resolution
• Compact and lightweight
• Electronic
transformer
• LED display menu with invert
• Display auto on/off
• Pan/tilt invert option
• Thermal switch
• Fan
cooled
O p t i o n a l C o n t r o l l e r s
• CA-9
Easy Controller
DMX Channel Summary
C HANNEL F UNCTION (16- BIT MODE ) C HANNEL F UNCTION (8- BIT MODE )
1 Pan 1 Pan
2 Pan Fine 2 Tilt
3 Tilt 3 Shutter
4 Tilt Fine 4 Color
5 Shutter 5 Gobo
6 Color 6 Gobo Rotation
7 Gobo
8 Gobo Rotation
Intimidator Spot 2.0 HTI Manual 5 2007-01-24/09:36
