DMX Mode
This mode allows the unit to be controlled by any universal DMX controller. If you are unfamiliar with
DMX, please read the DMX Primer on page 21.
1) Press until is displayed.
2) Use the and buttons to select the desired address and press the
button.
DMX Channel Values (16-bit mode)
C HANNEL V ALUE F UNCTION
1
000 Ù 255
Pan
0 – 540 (128 = halfway point)
2 000 Ù 255 Pan Fine
3
000 Ù 255
Tilt
0 – 270 (128 = halfway point)
4 000 Ù 255 Tilt Fine
5
000 Щ 108
109 Щ 133
134 Щ 249
250 Щ 255
Shutter and Dimmer
Closed > Open
Open
Strobe (Fast > Slow)
Open
6
000 Щ 015
016 Щ 031
032 Щ 047
048 Щ 063
064 Щ 079
080 Щ 095
096 Щ 111
112 Щ 127
128 Щ 191
192 Щ 255
Color Wheel
White (Open)
UV
Pink
Green
Red
Blue
Yellow
Magenta
Scroll counter-clockwise (Slow > Fast)
Scroll clockwise (Slow > Fast)
7
000 Щ 015
016 Щ 031
032 Щ 047
048 Щ 063
064 Щ 079
080 Щ 095
096 Щ 111
112 Щ 127
128 Щ 191
192 Щ 255
Gobo Wheel
Open
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Scroll counter-clockwise (Slow > Fast)
Scroll clockwise (Slow > Fast)
8
000 Щ 009
010 Щ 116
117 Щ 244
245 Щ 255
Gobo Rotation
Stop
Rotate counter-clockwise (Slow > Fast)
Rotate clockwise (Slow > Fast)
Boomerang gobo rotation* (Fast > Slow)
*Boomerang gobo rotation automatically rotates the
gobo in one direction, and then automatically rotates
it in the opposite direction an equal number of times.
Intimidator Spot 2.0 HTI Manual 18 2007-01-24/09:36
