TABLE 66: POWER PANEL ASSEMBLY - 115V (U.S.)
INDEX
PART NUMBER
DESCRIPTION
QTY
--
3281086
POWER ASSEMBLY - DOMESTIC - 20A
--
1
1571035
STANDOFF - PCB - 3/8 SNAP LOCK (OPTIONAL)
4
2
9989659
PCB ASSEMBLY - DUMB MECH POWER SUPPLY
1
3
9989100
INTERFERENCE FILTER
1
4
9900081
NUT #8-32 KEPS ZINC PLATE
2
5
9989046
24V XFMR-DUAL PIR.-.187 TERM
1
6
1211110
8-32X1/4 RHS MACH SCREW ZP
1
7
9984094
WIRE - GROUND - 14"
1
8
9989674
CIRCUIT BREAKER - 4 AMP
1
9
1709001
JUMPER - TRANSFORMER - FOREIGN
1
10
9989673
CIRCUIT BREAKER - 20A
1
11
1709006
JUMPER - MAIN SWITCH TO BREAKER
1
12
9984629
SWITCH - TOGGLE - DPST - 20AMP
1
13
6739021
HARNESS - POWER PANEL
1
14
1701025
PLATE - HOUSING - PANEL
1
