TABLE 65: POWER PANEL AND PCB ASSEMBLY
INDEX PART NUMBER DESCRIPTION QTY.
-- 3286006
MAIN CONTROL PCB WITH EPROM
(INCLUDES INDEX NUMBERS 1 AND 2)
--
1 9989755 PCB ASSEMBLY - MAIN CONTROLLER 1
2 SEE LABEL IC ASSEMBLY 1
3 --
BRACKET - SWITCH - INTERLOCK
(SEE TABLE 21 FOR DETAILS)
REF
4 9989687
PCB ASSEMBLY - EXECUTIVE INTERFACE
(USED WITH EXECUTIVE COIN MECHANISM OPTIONS)
OPT
5 3286010 PCB ASSEMBLY - COLD DRINK INTERFACE 1
6 9983778 TRIAC - 35 A - 600V 2
7 1571112 COVER - CONTROLLER AND INTERFACE PCB 1
8
3281086
POWER PANEL ASSEMBLY - 20A (U.S.)
(SEE TABLE 66 FOR DETAILS)
1 4521020
POWER PANEL ASSEMBLY - 230 V (U.K.)
(SEE TABLE 67 FOR DETAILS)
4521041
POWER PANEL ASSEMBLY - 230 V (FR./GER.)
(SEE TABLE 68 FOR DETAILS)
9 1671022 HOUSING - POWER PANEL 1
-- 1571029 MONEY BOX ASSEMBLY (NOT SHOWN) 1
