TABLE 40A: TUBING USAGE - MODEL 328
BULK TUBING PART NUMBERS
CONFIGURATION
LOCATION
USA
FRANCE/
GERMANY/
UK
GERMANY
GAS PUMPS
WITH SYRUP
BOXES
GAS PUMP TO SYRUP BOX
3108052
3638096
GAS PUMP TO SYRUP TUBE IN
WATER BATH
3108054
3158035
GAS PUMPS WITH
SYRUP TANKS
GAS PUMP TO REDUCER FITTING
3108052
3638096
3287122
REDUCER FITTING TO SYRUP TANK
DIP TUBE
3108054
3158035
3287121
GAS PUMP TO SYRUP TUBE IN
WATER BATH
3108054
3158035
3287121
SRYUP TUBE IN WATER BATH TO
DISPENSING SPOUT
3108054
3158035
3287121
TABLE 40B: TUBING USAGE - MODEL 327
BULK TUBING PART NUMBERS
CONFIGURATION
LOCATION
USA
FRANCE/
GERMANY/
UK
GERMANY
DIAPHRAGM
PUMPS WITH
SYRUP TANKS
SYRUP PUMP TO SYRUP TANK DIP
TUBE
3108054
3158035
SYRUP PUMP TO SYRUP TUBE IN
WATER BATH
3108054
3158035
SYRUP TUBE IN WATER BATH TO
DISPENSING SPOUT
3108054
3158035
