3. Assembly and Operation
First please put on the white gloves to avoid finger prints on the surface of the acrylic chassis during
installation.
1. Place first the lower part-chassis on a clean
and soft surface. Please pay attention, that the
surface of your HiFi-rack is horizontal and
vertical correctly adjusted, by using the
delivered level gauge. Important: Never turn
the Spikes of the turntable chassis, they had
been adjusted in the factory. Use the delivered
Flad Pads to avoid scratches on the surface of
your HiFi-rack. After that place the chassis with
the mounted bearing onto the first one.
2. Now unpack your turntable platter and place
the platter carefully on the upper part of the
bearing which is mounted in the turntable
chassis. Important: take care not to cause to
much pressure!
3. Place the pulley on the motor spindle. The
distance between the pulley and the motor
housing should be approx. 1-2mm. Tighten
the little screws inside the pulley with the
aluminium screwdriver provided.
