Champion
Level 1
USER MANUAL
Page 4
clearaudio electronic GmbH 2006
1
2
4
3
6
5
9
7
8
10
11 12
13
14
15
16
17
Overview of package contents
Not shown: a pair of white gloves
1.
Champion acrylic chassis with mounted bearing
10. Champion acrylic chassis (lower part)
2.
Complete preassembled stand-alone motor
11. REGA-counterweight
3.
Decuppeling device for the motor
12. REGA-tonearm base nut
4. Three
Flat Pads
to be lawn under the Spikes
13. Complete preassembled REGA-OEM tonearm
5.
Pulley made out of acrylic including fixing screws
14. Tube of grease for servicing the platter bearing
6.
Grounding cable to ground the bearing screw
15. High-precision turntable platter made out of solid
silicon acrylic
7.
clearaudio Clever Clamp
16. Hex key wrenches : one to adjust the tonearm
height, the other for the screws to mount the base
8.
Precision level gauge
17. Screw-driver made out of aluminium
9.
Two drive belts (one spare)
