11
Technical data
Payload 75 kg (165.3 lb)
FP-145 pedestal weight 130 kg (286.6 lb)
FPH-145 pedestal weight 118 kg (260.1 lb)
Trim weights 3 kg (6.6 lb)
Minimum height 66 cm (26 in.)
Maximum height 143 cm (56 in.)
Ground clearance 2 cm (0.8 in.)
On-shot stroke 76 cm (29.9 in.)
Doorway tracking width 78 cm (30.7 in.)
Wheel diameter 16 cm (6.3 in.)
Steering ring diameter 63.5 cm (25 in.)
Maximum working pressure 14.5 bar (210 psi)
Relief valve pressure 16.2 bar (235 psi)
Maximum floor speed (FP-145 pedestal only) 300 mm / sec (12 in. / sec)
Minimum floor speed (FP-145 pedestal only) 25 mm / sec (1.0 in. / sec)
Orientation accuracy (FP-145 pedestal only) Less than 0.75° (subject to floor)
Pedestal travel accuracy (FP-145 pedestal only) 0.5% of total floor run (subject to floor)
Maximum column speed 150 mm / sec (5.9 in. / sec)
Minimum column speed 10 mm / sec (0.4 in. / sec)
Height drive accuracy ±0.75mm (±0.03 in.)
Power consumption peak 750 W
Power input Autoranging 110-240V AC 50/60 Hz
Further information
For further information or advice regarding this pedestal, please contact Vinten Radamec (see back cover), or
visit our website.
For full details on maintenance and spare parts, please refer to the Fusion FP-145/FPH-145 Pedestal Mainte-
nance Manual and Illustrated Parts List - Publication Part No. V3952-4991. This is obtainable from Vinten Rad-
amec. For information on-line, visit our website at
www.vintenradamec.com
