PIN-OUT CONNECTIONS
PIN DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
GND
5V
PAN Z-
PAN Z+
PAN B-
PAN B+
PAN A-
PAN A+
N/C
GND
5V
TILT Z-
TILT Z+
TILT B-
TILT B+
TILT A-
TILT A+
N/C
N/C
PIN DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
GND
+5V
PAN V0-
PAN V0+
PAN V1-
PAN V1+
PAN V2-
PAN V2+
TILT V0-
TILT V0+
TILT V1-
TILT V1+
TILT V2-
TILT V2+
RS232 Tx
RS232 Rx
STATUS LIGHTS
LED CONDITION STATUS
POWER
PAN/TILT
5v Present
5v Not present
Normal (signal level 110% to 135%)
Optimum (signal level 90% to 110%)
Normal (signal level 70% to 90%)
Acceptable (signal level 50% to 70%)
Low (signal level <50%)
Index mark detected
Error (over signal)
Error (over speed)
Error (signal level <20%)
(ANY COLOUR)
Single flash
Off
KEY
Constant flash
Solid
