DMX Values
TOUR Channel Function Value Percent/Setting
1 Dimmer 000  255 0~100%
2
Module 1 Red
000  255
0~100%
Step Time Only when running custom programs
3
Module 1 Green
000  255
0~100%
Step Time Only when running custom programs
4 Module 1 Blue 000  255 0~100%
5 Module 1 White 000  255 0~100%
6 Module 1 Amber 000  255 0~100%
7 Module 2 Red 000  255 0~100%
8 Module 2 Green 000  255 0~100%
9 Module 2 Blue 000  255 0~100%
10 Module 2 White 000  255 0~100%
11 Module 2 Amber 000  255 0~100%
12
Color Macro +
White Balance
000  010
011  030
031  050
051  070
071  090
091  110
111  130
131  150
151  170
171  200
201  205
206  210
211  215
216  220
221  225
226  230
231  235
236  240
241  245
246  250
251  255
No function
R: 100% G: Up
B: 0%
R: Down G: 100% B: 0%
R: 0%
G: 100% B: Up
R: 0% G: Down B: 100%
R: Up G: 0% B: 100%
R: 100% G: 0% B: Down
R: 100% G: Up B: Up
R: Down G: Down B: 100%
R: 100% G: 100% B: 100% W: 100%
White 1: 3200 K
White 2: 3400 K
White 3: 4200 K
White 4: 4900 K
White 5: 5600 K
White 6: 5900 K
White 7: 6500 K
White 8: 7200 K
White 9: 8000 K
White 10: 8500 K
White 11: 10,000 K
13 Strobe
000  010
011  255
No Function
0~20 Hz
14
Auto + Custom
Programs
000  040
041  050
051  060
061  070
071  080
081  090
091  100
101  110
111  120
121  130
131  140
No function
Auto 1
Auto 2
Auto 3
Auto 4
Auto 5
Auto 6
Auto 7
Auto 8
Auto 9
Auto 10
COLORado Range IP QRG
Page 3 of 8
Features  3, 4, 5, 6, 7, 10, or 16 channels RGBWA LED wash light with two
tiltable panels
 Operating modes:
3-channel: HSV control
3-channel: RGB control
4-channel: RGB, dimmer
5-channel: RGBWA control
6-channel: RGBWA, dimmer
7-channel: RGBW, dimmer, strobe
10-channel: RGBWA in block mode (controls each panel
individually)
16-channel: Dimmer, RGBWA (block 1),RGBWA (block 2),
color macro, strobe, auto/custom, auto speed, dimmer
curve
 RGBWA static color mixing with or without DMX control
 Color temperature presets (3,200~10,000 K)
 Built-in automated programs
 Customizable programs
 Recall auto/custom programs via DMX
 Five distinct dimming curves
 Ingress Protection: IP66
 3-pin DMX input and output connectors
 LED display with password protection
 Die-cast aluminum, powder coated housing
 Color calibration
 Omega bracket mounting system
Options  15 optical system
CLENS1590
 30º optical system CLENS3090
 16.4 ft (5 m) IP66 power extension cable IP5POWER
 16.4 ft (5 m) IP66 signal extension cable
IP5SIG
 W-DMX (wireless DMX) receiver W-DMXIP66
 W-DMX (wireless DMX) transmitter
W-DMXTRANS
