Page 10/12
6. Repetitive checks
Repetitive checks are to be made on lifting bag systems as
follows:
9 Testing during acceptance
Check to ensure that all items are present and complete; this
is made by the person commissioned for the task.
A visual and function test is to be made by an instructed per-
son according to the operating instructions.
9 A visual and function test is to be made after each period of
use / application and carried out by the user.
This test is to be documented.
9 The lifting bag system is to undergo a visual test and function
test at least once each year by a specialist (*) and is to be made
according to the check list (available on request).
This test is to be documented.
(*) Qualification see premilinary remarks on GUV G 9102
9 At least every 5 years, or if there is any doubt about the safety
or reliability, the lifting bag system is to be tested according
to GUV-G 9102 (formally GUV 67.13) by the manufacturer.
The responsibility for the correct and professional execution of
the repetitive test lies with the user!
7. Technical data
Lifting bag 1 bar / 14.5 psi 6 t (Art.-No. 3110007702)
Lifting power
to 6.0
Us tons 6.6
Lifting height, max.
cm 60
inch 23.4
Insertion height (uninflated)
cm 3/4/6
inch 1.2/1.6/2.3
Dimensions
cm 80 x 80
inch 31.2 x 31.2
Working pressure
bar 1
psi 14.5
Test pressure
bar 1.5
psi 21.8
Air requirement at 1 bar
l 506
cu. ft 17.9
Weight, approx.
kg 10.4
lbs 22.9
All rights reserved for technical changes within the scope of product improve-
ment.
