Owner’s Manual and Operating Instructions
The Automatic Voice/Pager Dialer System
For The Next Millennium
Congratulations!
Thank you for purchasing United Security Products, Inc.’s Model AVD-2010 - the “smartest”, most compre-
hensive automatic voice/pager security dialer available. Representing an exciting new level of achievement, the
AVD-2010 combines technologically advanced features, ease of programming and reliable operation in a com-
pact, unobtrusive dialer completely compatible with any security alarm system. Installation and hookup are
quick and easy, whether installed in conjunction with normally open, normally closed dry contact or voltage
activation sensors. The unit can also function as a stand-alone device, by simple connection to an ordinary tele-
phone jack. The keypad cover glides on and off for added attractiveness and security.
How It Works
The AVD-2010 features a “smart’ Power Monitoring Sys-
tem (PMS) that constantly operates in the background with-
out interfering with any of the dialer functions under nor-
mal power conditions. In the event of a blackout, or when
battery voltage falls below a safe level, or when power is
restored, the PMS automatically dials out and notifies by
means of pre-recorded voice messages which of the three
conditions have been detected: “AC POWER OFF”,
“BATTERY LOW”, or “AC POWER RESTORED”.
The AVD-2010 is extensively programmable, offering per-
sonalized customization to fulfill virtually any residential or
business requirement. Plain-English prompts walk the user
through the process in a timely manner.
Programming options abound, allowing the user to:
•
Store up to 8 telephone/pager numbers.
•
Choose 1- 9 calling efforts for the numbers dialed.
•
Select 1-3 message repeats.
•
Record a variable combination (maximum: 7) of in-
structional outgoing messages (total elapsed time: 60
seconds).
Program up to 4 separate input channels with individually
enable/disable, entry/exit delay and activation options (Nor-
mally Open (N.O.), Normally Closed (N.C.)
(dry contact or voltage activation) including momentary and
continuous activation for each).
Further individualize each channel by selecting the delay
times, telephone/pager numbers to be dialed and the specific
outgoing messages to be played.
Please Familiarize Yourself With These Instructions Before
Installation/Operation. This guide describes how to program
and operate the dialer. We strongly recommend that you read
the entire manual before attempting to use the unit.
To enhance ease of programming and operation, this guide
includes:
•
A Programming Sample/Quick Setup review on page 13
with a corresponding Program Planner.
•
A Blank Program Planner on page 14. One copy of this
Planner should be kept in a safe place by the end user.
A separate copy should also be retained by the installer.
We are happy to provide a full measure of security reassur-
ance and peace of mind with the Model AVD-2010. For in-
formation about other innovative United Security Products
equipment, call (800) 227-1592.
M O D E L A D - 2 0 0 0
For Technical Service and Support: Call (858) 413-0149 * Fax (858) 413-0124
E-mail: [email protected]
Monday – Friday * 6:30 AM – 4:00 PM PST
MODEL AVD-2010
