18
Electrical / Dimensions
Power source:
Current (OPERATE mode – standby):
Current (OPERATE mode – dialing):
Activation:
Max. digits for outgoing numbers:
Operating temperature range:
Dimensions (inches):
Weight (ounces):
Mounting:
Case Material:
Color:
Warranty: 9-18VDC
28mA typical.
100mA max.
1)
N.C. Activation: dialer activates when an “open” is detected
2) N.O. Activation: dialer activates when a “close” is detected
3) Voltage Activation: N.C. (applied voltage: Min. +5VDC, Max. +28VDC)
N.O. (loss of continuous voltage: Min. 0VDC, Max. 0.25VDC)
50
-18 to 55 C (0 to 130 F)
6 x 4 x 2 3/16 inch
10 oz
Wall or Flat Surface
ABS
White
1 Year
Note: Design and specifications subject to change without notice.
Power Source
AC-2P: AC/DC Adaptor (included with AVD-4040)
Plugs into regular 110VAC outlet to provide the dialer with the
required primary power.
AC-2: AC/DC Adaptor
12VDC/0.5A for stand alone with siren use.
PP-1: Power (Rechargeable)
Provides 12 (est.) hours of backup standby power.
PB12P:
Includes AC-2P that plugs into regular 110VAC outlet to pro-
vide power to PB12P backup battery for primary power and 12
(est.) hours of standby power
IR-1: Isolation Relay
Converts alarm output voltage to N.C. to provide clean input
trigger to dialer.
Industrial/Residential Sensors
F20: Temperature Supervisory Switch <40 F
HTS: High Temperature Switch
WLS: Water Level Sensor
RTS: Adjustable Temperature Controller, N.O., N.C.
PLS: Power Loss Sensor (110VAC)
Sensors
Magnetic Contacts – Door and Window
Glass Break Detectors
Hold Up Buttons/Emergency Switches
Pressure Mats – Sealed and Under Carpet
Motion Detectors
Siren
S-120: 2” Mini Siren, 12VDC @ 120 mA typical
NOTE: CALL UNITED SECURITY PRODUCTS FOR
ADDITIONAL INFORMATION AND DEVICES NOT LISTED
HERE.
S P E C I F I C A T I O N S
D I A L E R A C C E S S O R I E S
16.75oz
IMPORTANT
See additional electrical ratings
Remote Responder System page 14
