Principal parts of the machine – SINGER 2277 TRADITION Instruction Manual User Manual
Page 11
14. Horizontal spool pin
15.
16. Hole for second spool pin
17. Handwheel
18. Power and light switch
19. Main plug socket
20. Bobbin thread guide
21. Upper thread guide
22. Face plate
23. Handle
24.
25. Foot speed control
26. Power cord
Bobbin winding spindle
Presser foot lifter
4
Principal Parts of the Machine
25
26
18
19
14
15
17
16
20
21
22
24
23
GB
