SINGER 44S CLASSIC HEAVY DUTY - Manual (Page 19)

- Place thread and corresponding spool holder on to spool
pin. (1/2)
- Snap thread into thread guide. (3)
- Wind thread clockwise around bobbin winder tension discs. (4)
- Thread bobbin as illustrated and place on spindle. (5)
- Push bobbin spindle to right. (6)
- Hold thread end securily. (7)
- Step on foot control pedal. (8)
- Trim thread close to the bobbin & then continue winding
until bobbin is full. (9)
- Cut thread, push bobbin spindle to left (10) and remove.
When the bobbin winder spindle is in "bobbin winding"
position, the machine will not sew and the
.
To start sewing, push the bobbin winder spindle to the left
(sewing position).
Please Note:
handwheel turn
1
2
4
7 8 9
5 6
3
10
Winding the Bobbin EN
12
