Principal parts of the machine – SINGER 3229 SIMPLE User Manual
Page 11
12. Horizontal spool pin
13. Bobbin winding spindle
14. Hole for second spool pin
15. Handwheel
16. Power and light switch
17. Main plug socket
18. Bobbin thread guide
19. Upper thread guide
20. Face plate
21. Handle
22. Presser foot lifter
23. Foot speed control
24. Power cord
4
Principal Parts of the Machine
23
24
16
17
12
13
15
14
18
19
20
22
21
EN
